7 MAINTENANCE
7.1 VISUAL INSPECTION
Due to the critical nature of perimeter surveillance applications, it is of paramount importance to keep
the radar units trouble-free by routinely conducting visual verifications. The visual verification must
check the following:
• Verify that the radome is clear from any obstruction such as trees or branches or any natural
formation of dirt, grime or bird deposits. Such formations may attenuate radar signals. In order
to clean the radome, see directions below (Section 7.3).
7.2 RECOMMENDED MAINTENANCE SCHEDULE
Maintenance
Item/Action
Frequency Comments
CLEANING Dependent on the environment
MECHANICAL INSPECTION Every year
To be done only by a trained
technician or return to FLIR for
inspection
MOTOR Change every 3 years Return to FLIR for maintenance
GASKET
Immediately
if damaged
.
Otherwise change every 3 years
SLIP RINGS Change every 2 years Return to FLIR for maintenance
SUPER CAPS Change every 3 years Return to FLIR for maintenance
GORE
™
MEMBRANE VENTS
Depende
nt on
the
environment
Recommended every 2 years
Table 14 – Recommended Maintenance Schedule
