Pin configurations

25.1 Pin configuration for USB Mini-B connector

1. +5 V (out)

2. USB –

3. USB +

4. N/C

5. Ground

25.2 Pin configuration for video connector

1. Audio right

2. Ground

3. Video out

4. Audio left

25.3 Pin configuration for USB-A connector

1. +5 V (in)

2. USB –

#T559879; r. AO/35410/35410; en-US

150
