About FLIR Systems
30
with a worldwide network of agents and distributors—support our international customer
base.
FLIR Systems is at the forefront of innovation in the infrared camera industry. We antici-
pate market demand by constantly improving our existing cameras and developing new
ones. The company has set milestones in product design and development such as the in-
troduction of the first battery-operated portable camera for industrial inspections, and the
first uncooled infrared camera, to mention just two innovations.
Figure 30.2 1969: Thermovision Model 661. The
camera weighed approximately 25 kg (55 lb.), the
oscilloscope 20 kg (44 lb.), and the tripod 15 kg
(33 lb.). The operator also needed a 220 VAC gen-
erator set, and a 10 L (2.6 US gallon) jar with liquid
nitrogen. To the left of the oscilloscope the Polaroid
attachment (6 kg/13 lb.) can be seen.
Figure 30.3 2015: FLIR One, an accessory to
iPhone and Android mobile phones. Weight: 90 g
(3.2 oz.).
FLIR Systems manufactures all vital mechanical and electronic components of the camera
systems itself. From detector design and manufacturing, to lenses and system electronics,
to final testing and calibration, all production steps are carried out and supervised by our
own engineers. The in-depth expertise of these infrared specialists ensures the accuracy
and reliability of all vital components that are assembled into your infrared camera.
30.1 More than just an infrared camera
At FLIR Systems we recognize that our job is to go beyond just producing the best infrared
camera systems. We are committed to enabling all users of our infrared camera systems
to work more productively by providing them with the most powerful camera–software
combination. Especially tailored software for predictive maintenance, R & D, and process
monitoring is developed in-house. Most software is available in a wide variety of
languages.
We support all our infrared cameras with a wide variety of accessories to adapt your equip-
ment to the most demanding infrared applications.
30.2 Sharing our knowledge
Although our cameras are designed to be very user-friendly, there is a lot more to thermog-
raphy than just knowing how to handle a camera. Therefore, FLIR Systems has founded
the Infrared Training Center (ITC), a separate business unit, that provides certified training
courses. Attending one of the ITC courses will give you a truly hands-on learning
experience.
#T559879; r. AO/35410/35410; en-US
169

Table of Contents

Other manuals for FLIR T420

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the FLIR T420 and is the answer not in the manual?

FLIR T420 Specifications

General IconGeneral
Resolution320 x 240 pixels
Field of View25° x 19°
Spatial Resolution (IFOV)1.36 mrad
Image Frequency60 Hz
Laser PointerYes
Operating Temperature Range-15°C to +50°C
Storage Temperature Range-40°C to +70°C
Image StorageSD Card
Temperature Range-20°C to +650°C
FocusManual
Display3.5 in. LCD
Battery LifeApprox. 4 hours
Accuracy±2°C or ±2%
Digital Camera3.1 MP
Video RecordingYes
File FormatJPEG
Spectral Range7.5 - 13 µm
Minimum Focus Distance0.4 m
Weight0.88 kg
InterfaceUSB, Wi-Fi
Image ModesThermal, MSX
Thermal Sensitivity< 0.045°C @ +30°C (+86°F) / 45 mK
