FLIR T420 User Manual

Technical data24
24.6 FLIR T420 (incl. Wi-Fi)
P/N: 62103-1101
Rev.: 35207
General description
The FLIR T420 is a camera that offers good performance at an affordable price. Excellent ergonomics, a
walk-up-and-use interface, and easy communication make the FLIR T420 a truly user-friendly camera for
the beginner or advanced user.
Benefits:
• Excellent ergonomics: The FLIR T420 has a tiltable infrared unit and auto-orientation, which make it
easy to capture images from any angle comfortably. The small size and low weight of the camera facil-
itate its use over a full working day.
• Affordable performance: The FLIR T420 is equipped with the innovative Multi Spectral Dynamic Imag-
ing (MSX) feature, which produces an image richer in detail than ever before. You can highlight ob-
jects of interest, on both the infrared and the visual images, by sketching or adding predefined stamps
directly onto the camera’s touch screen.
• Extensive communication options: The Wi-Fi connectivity of the FLIR T420 allows you to connect to
smart phones or tablets, for the wireless transfer of images or the remote control of the camera. The
Bluetooth-based METERLiNK function transfers readings from external measurement instruments to
the infrared image.
• Support for UltraMax: When enabling UltraMax in the camera, the resolution of images can be sub-
stantially enhanced when importing the images into FLIR Tools.
Imaging and optical data
IR resolution 320 × 240 pixels
MSX resolution 320 × 240 pixels
UltraMax Yes
Thermal sensitivity/NETD <40 mK @ +30°C (+86°F)
Field of view (FOV)
25° × 19°
Minimum focus distance 0.4 m (1.31 ft.)
Focal length 18 mm (0.7 in.)
Spatial resolution (IFOV) 1.36 mrad
F-number 1.3
Image frequency 60 Hz
Focus Automatic (one shot) or manual
Digital zoom 2× and 4×
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
7.5–13 µm
Detector pitch 25 µm
Image presentation
Display Touch screen, 3.5 in. LCD, 320 × 240 pixels
Auto orientation Automatic landscape or portrait
Image adjustment Auto or manual
Image presentation modes
Thermal MSX
Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable IR area on visual image
#T559879; r. AO/35410/35410; en-US
78

FLIR T420 Specifications

General

Resolution	320 x 240 pixels
Field of View	25° x 19°
Spatial Resolution (IFOV)	1.36 mrad
Image Frequency	60 Hz
Laser Pointer	Yes
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Image Storage	SD Card
Temperature Range	-20°C to +650°C
Focus	Manual
Display	3.5 in. LCD
Battery Life	Approx. 4 hours
Accuracy	±2°C or ±2%
Digital Camera	3.1 MP
Video Recording	Yes
File Format	JPEG
Spectral Range	7.5 - 13 µm
Minimum Focus Distance	0.4 m
Weight	0.88 kg
Interface	USB, Wi-Fi
Image Modes	Thermal, MSX
Thermal Sensitivity	< 0.045°C @ +30°C (+86°F) / 45 mK
