Floe MAXIS - Bill of Materials and Exploded View

SHEET 2 OF 8
BILL OF MATERIALS/EXPLODED VIEW
P/N 512-65030-00 KIT, MAXIS EXTENSION 6-10K
NUMBER PART NUMBER QTY. DESCRIPTION
1 001-70207-00 2 HHCS, ½-13 x 1 ¼” 18-8 ss
2 001-71021-00 2 FLAT WASHER, ½” 18-8 SS
3 001-76072-00 2 NUT, NYLOCK ½-13 ALUM.
4 002-00257-00 2 TUBE, MAXIS LEG EXTENSION 6-10K – 12”
5 002-00258-00 2 INSERT, CANOPY 6-10K W/ PIVOT HOLE – 44”
6 112-01075-00 2 ASS’Y, CANOPY INSERT W/ GUIDE HOLES – 44”
