SHEET 2 OF 8
BILL OF MATERIALS/EXPLODED VIEW
P/N 511-06005-00 EXTENSION LEGS, V2000-VSD5000
NUMBER PART NUMBER QTY. DESCRIPTION
1 001-70218-00 2 HHCS, ½-13 x 3 ¾” 18-8 ss
2 001-76072-00 2 NUT, NYLOCK ½-13 ALUM.
3 111-00219-00 2 WELD’T, EXTENSION LEG – 27”
P/N 511-06006-00 EXTENSION LEGS, VSD6000-8000
NUMBER PART NUMBER QTY. DESCRIPTION
1 001-70224-00 2 HHCS, ½-13 x 5 ½” 18-8 ss
2 001-76072-00 2 NUT, NYLOCK ½-13 ALUM.
3 111-00220-00 2 WELD’T, EXTENSION LEG – 20.5”
