SHEET 3 OF 8
PLACEMENT
LEG EXTENSIONS CAN BE PLACED ON ANY END OR CORNER OF THE BOAT LIFT (ON CORNER POSTS
“A” & “D” OR “B” & “C”). WHEN CHOOSING A LOCATION, ENSURE THAT THE LIFT WILL BE STABLE UPON
INSTALLATION.
EXTENSIONS ON CORNER
POSTS “A” & “D”
EXTENSIONS ON CORNER
POSTS “B” & “C”
EXTENSIONS ON CORNER
POSTS “C” & “D”
EXTENSIONS ON CORNER
POSTS “A” & “B”
EXTENSIONS ON
CORNER POSTS
“B” & “D”
(CAN BE PLACED ON “A” & “C”
ALSO)
