SHEET 4 OF 8
INSTALLATION
RAISE END OF LIFT WITH A HIGH LIFT JACK (OR EQUIVALENT) THAT WILL HAVE THE LEG EXTENSIONS
INSTALLED ON. FOR SMALL LIFTS, RAISE FRAME BEAM 44” ABOVE THE GROUND (FIGURE 1.1). FOR
LARGE LIFTS, RAISE FRAME BEAM 38” ABOVE THE GROUND (FIGURE 1.1A). REMOVE ½” NYLOCK NUT
AND ½” BOLT ON EACH SANDPAD, THEN REMOVE SAND PADS (FIGURE 1.2).
IMPORTANT NOTE
FOR INSTALLATION OF LEG
EXTENSIONS, THE LIFT MUST BE RAISED
ON ONE END (BOTH IF INSTALLING
TWO KITS). BE SURE TO PROPERLY
SUPPORT THE LIFT TO AVOID
TIPOVER,
FIGURE 1.1
2X
FIGURE 1.2
FIGURE 1.1A
