Floe VSD - Step 3: Reassembling and Reconnecting the VSD Unit

STEP 3
APPLY THE ENTIRE CONTENTS OF THE ANTI-SEIZE TO THE MOTOR SHAFT OF THE DRIVE UNIT
(FIGURE 3.1). INSTALL THE DRIVE UNIT ONTO THE END OF THE BALL SCREW (FIGURE 3.2).
12
FIGURE 3.1
FIGURE 3.2
