RE-INSTALL THE PREVIOUSLY REMOVED FASTENERS TO SECURE THE MOTOR TO THE BALL
SCREW CLAMP (FIGURE 3.3). TIGHTEN FASTENERS UNTIL THERE IS A 1/8” GAP BETWEEN THE
MOTOR PLATE AND BALL SCREW CLAMP (FIGURE 3.4).
FIGURE 3.3
FIGURE 3.4
