Floe VSD - Page 7

REMOVE THE (4) FASTENERS SECURING THE MOUNT TO THE COVER. FOR VSD3800/5000 LIFTS,
USE A 5/32” HEX BIT/ALLEN WRENCH TO REMOVE THE BOLTS (FIGURE 2.3). FOR VSD6000-10,000
LIFTS, USE A 1/4” HEX BIT/ALLEN WRENCH TO REMOVE THE BOLTS (FIGURE 2.4).
DO NOT DISCARD BOLTS, THEY WILL BE RE-USED.
7
FIGURE 2.3
FIGURE 2.4
