REMOVE THE MOTOR FROM THE COVER. REMOVE THE FOAM FROM THE MOTOR AND REPLACE
WITH THE INCLUDED FOAM BY PEELING THE BACKING OFF OF THE DOUBLE SIDED TAPE AND
PRESSING ONTO MOTOR CASE (FIGURE 2.5). PLACE THE NEW COVER OVER THE MOTOR WHILE
ALIGNING THE MOUNTING HOLES ON THE MOTOR AND COVER. INSTALL THE INCLUDED
SPACERS AS SHOWN (FIGURE 2.6).
8
FIGURE 2.6
FIGURE 2.5
INSTALL NEW FOAM ONTO MOTOR
