-WHEN ENTERING OR EXITING LIFT, THE TOP OF THE BUNKS SHOULD BE APPROXIMATELY 4 TO 5 ½
INCHES OUT OF THE WATER, DEPENDING ON BOAT AND AMOUNT OF DRAFT (FIGURE 2.5B).
IMPORTANT: FAILURE TO SET BUNK HEIGHT CORRECTLY WILL RESULT IN DAMAGE
TO BOAT, BUNKS, AND/OR LIFT.
4X
FIGURE 2.6
FIGURE 2.5B
WATER
LEVEL
