23
meter is fitted with PTFE encapsulated seals as the PTFE sheath is sensitive to damage from
re-use.
Fit the cover plate (5) and the meter cap screws (6), and tighten the screws in a star
sequence. Torque the meter cap screws in the same sequence to 4NM for 004/006/008
meters or 6NM for 015/020 meters. Reconnect wiring as appropriate.
7. Spare Parts
Refer to images in section 6 for identification of spare parts.
7.1 Small Capacity Models
Aluminium BSP body assembly
Aluminium NPT body assembly
SS Rotors with Bronze bushings
– suits STD PCB
SS Rotors with Bronze bushings
– suits FC PCB
SS Rotors with Carbon bushings
– suits STD PCB
SS Rotors with Carbon bushings
– suits FC PCB
PPS Rotors – suits STD PCB
PPS Rotors – suits FC PCB
Aluminium cap assembly with
Standard PCB
Aluminium cap assembly with
Fuel Consumption PCB
Stainless Steel cap assembly
with Standard PCB
Stainless Steel cap assembly
with Fuel Consumption PCB
A2-70 Button Head Cap Screws
