Flomec EGM Series - Medium Capacity Models

6
1.2.2 Medium Capacity Models
Model
EGM015
EGM020
Nominal Size
15mm / 1/2”
20mm / 3/4”
Nominal 3cP Flow range (L/min)
1 ~ 40
3 ~ 80
Nominal 3cP Flow range (GPM)
0.3 ~ 10.6
0.8 ~ 21.1
Accuracy ( liquids ≥ 3cP)
± 0.5% of reading
Additional error for
Uncalibrated Meters
± 0.5% of reading
Repeatability (liquids ≥ 3cP)
Typically ± 0.03%
Temperature Rating
-15
o
C ~ +80
o
C (5
o
F ~ +176
o
F)
Pressure Ratings – Bar (PSI)
Aluminium
20 (290)
20 (290)
Stainless Steel
20 (290)
20 (290)
Flow Ranges for Various Viscosity Liquids - L/min (GPM)
1cP
1
1.5 ~ 32
(0.40 ~ 8.45)
5 ~ 64
(1.32 ~ 16.9)
7cP
0.5 ~ 40
(0.13 ~ 10.57)
2 ~ 80
(0.53 ~ 21.1)
200cP
0.4 ~ 40
(0.11 ~ 10.57)
1.8 ~ 80
(0.48 ~ 21.1)
500cP
0.3 ~ 40
(0.08 ~ 10.57)
1.5 ~ 80
(0.40 ~ 21.1)
1000cP
2
0.2 ~ 25
(0.05 ~ 6.60)
1 ~ 50
(0.26 ~ 13.2)
Nominal Output Pulse Resolution – Pulses/Litre (Pulses/USGallon)
Standard Hall Effect
170 (644)
105 (398)
Fuel Consumption Option
42.5 (161)
26.3 (99.5)
Minimum Filtration
75 micron (200 mesh)
3
Notes:
4. When operating on 1cP liquids the meters may be used up to the nominal (3cP) maximum flow rate rating
for intermittent periods only.
5. For applications above 500cP the maximum flowrate must be reduced according to the table above, for
applications above 1000cP the maximum flow rate must be reduced further in order to limit the maximum
pressure drop across the meter to below 1Bar (14.5psi). Consult the manufacturer if you are unsure.
6. Filtration requirements are for soft particles only; hard particles of any size are not acceptable.
