Flotec FP4800 Series - Additional Repair Parts; Parts for FP4112 and FP4122 Models

Repair Parts 12
For parts or assistance, call Flotec Customer Service at 1-800-365-6832
Ref. Part Description FP4112 and FP4112C FP4122 and FP4122C
1 Motor J218-582A-115-PKG J218-590PKG
2 Seal Plate Assembly N3-1043P
3 Seal and Gasket Kit** FPP1550
4 Pump Body Assembly
§
N176-38 N176-38F
5 Overhaul Kit
§§
FPP1560 FPP1561
6 Pressure Switch TC2151
** Includes: Water slinger, seal plate O-Ring or gasket, shaft seal, and diffuser O-Ring or gasket.
§
Includes: Pump body, nozzle, and venturi.
§§
Includes: Seal and Gasket Kit (Ref. 3), impeller, and diffuser.
1
2
3
5 (Includes
Key No. 3)
6
4
AVC
Port
