ESL Intensifier
007000-2 (Rev. Z)
40K intensifier assembly
ItemQty Part # Description
4 2 007038-2 Cylinder end
6 1 007304-2 End bell
8 1 007304-1 End bell
10 2 B-1465-2 Seal ring
12 2 B-6313-2 Seal backup sleeve
14 2 A-14469 Rod seal
16 2 A-0264-131 Snap ring
18 2 013461-1 Oil seal spacer
20 4 C-5282-1 High-pressure seal
22 4 001194-1 Hoop seal
24 4 B-8075-122 Ultra HP o-ring
26 1 007201-1 Piston biscuit
28 2 006881-1 Biscuit spacer
30 2 013458-1 Plunger assembly
32 2 A-0270-300 Snap ring
33 2 A-00251-22 Rod T-seal
36 2 A-1001 Poly pak seal
37 2 A-2838 High-pressure gland
38 2 A-2839 High-pressure collar
39 AR A-4689 Food grade grease
40 4 B-1000-2 Tie rod
ItemQty Part # Description
41 1 C-1000-1 Low-pressure cylinder
42 2 321276 End cap
43 2 A-0063-023 O-ring
44 2 A-0275-240 O-ring
45 2 A-00250-240 Back-up ring
46 8 A-1000 Hex nut
47 1 010640-1 Label
48 2 004345-1 Quick coupling nipple
49 2 A-0274-6 O-ring
50 AR A-2185-2 High-friction lubricant
52 2 004383-2 Check valve body
53 2 004380-1 Retaining screw
54 2 004382-1 Insert
55 2 005917-1 Outlet poppet
56 4 A-0275-125 O-ring
57 2 A-1606 Compression spring
58 2 C-1313-1 Outlet body
59 2 010564-1 Inlet support
60 2 015384-1 Inlet poppet
101 AR A-2185 Blue Lubricant
102 AR A-3202 Loctite
34 | M-310 © Flow International Corporation
