Table 2. Dimensions (Unit: mm)
Diameter DN a D Do n × Φ A
10 230 90 60 4 × 14
15 230 95 65 4 × 14
20 230 105 75 4 × 14
25 230 115 85 4 × 14
32 230 140 100 4 × 18
40 230 150 110 4 × 18
50 230 165 125 4 × 18
65 230 185 145 8 × 18
80 230 200 160 8 × 18
100 230 220 180 8 × 18
125 280 245 210 8 × 18
150 280 285 240 8 × 22
200 310 340 295 12 × 22
250 360 405 355 12 × 22
300 460 460 410 12 × 22
350 460 520 470 16 × 22
400 460 580 525 16 × 26
450 460 640 585 20 × 26
500 600 715 650 20 × 26
600 600 840 770 20 × 30
700 700 895 840 24 × 33
800 800 1015 950 24 × 33
900 900 1110 1050 28 × 33
1000 1000 1230 1160 28 × 36
1200 1200 1405 1340 32 × 33
1400 1400 1630 1560 36 × 36
1600 1600 1830 1760 40 × 36
1800 1800 2045 1970 44 × 39
2000 2000 2265 2180 48 × 42
2200 2200 2405 2315 52 × 45
