Argus Ball Valve EK, FK and HK Operating Manual – BA1000 EN
1 General Information
Page 14 of 67
[1] Nominal Pressure (Class/PN)
[2] Argus Type
[3] Nominal Size
[4] Order Number & Order Item (from Flowserve Flow Control GmbH)
[5] Material Combination
[6] Test Pressure
[7] Fabrication Number (Serial Number)
[8] Permissible Maximum & Minimum Temperature – TS*
[9] Date of Manufacture
[10] Maximum Permissible Operating Pressure at Room Temperature – PS*
[11] Article Number
*Observe temperature-dependent limit values for the pressure load for non-metallic
sealing material. Refer to Annex C: Pressure-Temperature Diagrams for Ball Seats.
CE marking according to European Pressure Equipment Directive 2014/68/EU (PED):
According to the provisions of European Pressure Equipment Directive 2014/68/EU,
Argus Ball Valves and equipment classified in Category II and above are marked
with the CE symbol and the identification number of the notified body (“0036”).
Argus Ball Valves in Category I are marked with “CE” only. Argus Ball Valves which,
due to their design, are not covered by the Directive do not bear the CE marking.
The attached EU conformity declaration according to 2014/68/EU certifies that the
provisions from the Directive have been fulfilled for the affected Argus Ball Valves
and equipment.
