Flowserve FlowAct Series User Manual

FlowAct Diaphragm Linear Actuator FCD VLENIMFACTA4 10/16
57
flowserve.com
Pneumatic Actuator - Type 3002
• Type 253, 503, 701 see page 17
• Type 1502 see page 39
Adjustable Limit Stop - max. positioning force 39 kN
see pages 48 - 49
Single chamber actuator without attachments Single chamber actuator with attachments
Spring-to-close Spring-to-open Spring-to-close Spring-to-open
see pages 58 - 61 see pages 62 - 65 see pages 66 - 69 see pages 70 - 73
Central-mounted handwheel
without
see pages 50 - 53
NAMUR-yoke, with double mounting pads
see page 54
