Limitorque Actuation Systems L120 Series FCD LMENIM1201-05-A4 – 03/18
6
Figure 2.1 – L120-10 through 40
Motor
Limit Switch/
Controls
Compartment
Housing
Declutch
Lever
Handwheel
Actuator
Nameplate
(hidden)
