Flowserve Scienco SEM-10 User Manual

3
Technical Specifications
Inlet Port, SEM-10 ------------------------- 1-inch Male NPT
Outlet Port, SEM-10 ------------------------- 1-inch Male NPT
Inlet Port, SEM-10FT ------------------------- 1-inch Female NPT
Outlet Port, SEM-10FT ------------------------- 1-inch Male NPT
Flow Range ------------------------- 2 to 30 GPM
Maximum Pressure ------------------------- 60 PSI (410 kPa)
Accuracy ------------------------- +- 0.5%
Maximum Total ------------------------- 999,999.9
Battery ------------------------- Lithium CR 2032 (3 Volt)
Auto Shut Off ------------------------- 40 Seconds
Auto Wake Up ------------------------- With Flow
Material of Construction
Fluid Housing/Form Cover ------------------------- Nylon or Polypropylene
Meter Chamber ------------------------- Polypropylene Sulfide
(PPS), Stainless Steel
O-rings ------------------------- Viton or EPDM
Electronic Housing ------------------------- Nylon
Screws ------------------------- Stainless Steel
Note: The Polypropylene SEM-10 and SEM-10FT is designed to pump chemicals with a low
PH. Ensure chemical compatibility between liquid metered and the meter’s wetted parts
before using.
Note: Meter should NOT be used to transfer flammable petroleum products. Do NOT use with
fluids that have a flashpoint lower than 100°F.

Flowserve Scienco SEM-10 Specifications

General

Brand	Flowserve
Model	Scienco SEM-10
Category	Measuring Instruments
Language	English
