Flowserve Scienco SEM-10 User Manual

11
Parts List and Parts Diagram
Note: All parts are common to the polypropylene
SEM-10 and SEM-10FT except the fluid housing.
For additional assistance please call
Flowserve-Scienco Sales Department: 1-800-343-PUMP (7867)
Polypropylene/Nylon SEM-10/SEM-10FT Parts List
Qty. Part No. Description
8 PH-13 SS. Screw, Long
1 S10-11 COMPLETE Electronics Assembly
1 S10-12 Meter Gasket
4 PH-03 SS. Screw, Short
1 S10-02 Meter Plate
1 SEM-10 KIT-2
Metering Chamber
Kit:
S10-03 or S10-07
S10-04 or S10-08
SFM10000-01
SFM10000-02
SFM10000-03-0A
S10-14
1 S10-05/05N
SEM-10 Fluid
Housing
1 S10-10/10P
SEM-10FT Fluid
Housing
