Meter Installation Procedures
Flow can be metered in either direction through the SEM-10 and SEM-10FT meters.
SEM-10: Thread the meter inlet into the female discharge port of the pump. Using an elbow or
coupling, screw the discharge hose onto the other port of the meter. Use thread sealant tape,
or pipe dope to seal threaded connections.
SEM-10FT: Thread the meter inlet (female threads) onto the end of the hose. Install a 1-inch
ball valve on the meter outlet (male threads). Use thread sealant tape, or pipe dope to seal
threaded connections.
! CAUTION !
DO NOT OVERTIGHTEN THREADED CONNECTIONS.
BREAKAGE CAN OCCUR, RESULTING IN EXPOSURE TO FLUID.
! CAUTION !
DO NOT MOUNT METER IN A LOAD BEARING MANNER. EXCESSIVE LOADS CAN
CAUSE BREAKAGE, RESULTING IN FLUID EXPOSURE AND LEAKAGE.
Battery Removal/Replacement
If the LCD display becomes dim, the battery should be replaced. The meter electronics can be
removed without exposure to the fluid inside the meter.
! CAUTION !
OPEN VALVE TO RELIEVE SYSTEM PRESSURE AND DO NOT
PRESSURIZE SYSTEM DURING THIS PROCEDURE.
