Fluidmaster 400A User Manual

10 11
A: ATTACH WATER
SUPPLY CONNECTOR
TO FILL VALVE
Twist to the right
(counterclockwise)
RIGHT
C: WATER LEVEL
After the tank stops filling, water level should fill the tank to
roughly ½ inch below top of overflow pipe to ensure a proper
flush.
STEP 5: FINISHING STEPS
TOP DOWN VIEW
TURN
COUNTER-
CLOCKWISE
See page 12 to fine-tune
TANK Water Level
1/2"
Water Level
Overflow Pipe
Top of
Overflow Pipe
B: TURN ON WATER
Check for leaks.
(See Troubleshooting for
leak solutions)

Fluidmaster 400A Specifications

General

Model	400A
Type	Toilet Fill Valve
Material	Plastic
Adjustable Height	Yes
Universal Fit	Yes
Warranty	5 year
