fluidra 66178 User Manual

0000137242 Rev. 7.1 22
4 PROGRAMMING
When turned on, the system automatically goes into measurement and dosing mode – RUN function.
Press the ESC and ENTER keys simultaneously to enter the programming mode. Next, press ENTER to access
the various menus. In this manner, all of the outputs will be disabled.
Use the UP and DOWN keys to scroll through the various menus and submenus and to modify the data
(increase/decrease).
Use the ENTER key to access the data insertion submenus and to confirm any modifications.
Use the ESC key to return to the previous menu or function without saving any changes.
All of the instrument’s main menu items are shown below:
4.1 LANGUAGE MENU (menu navigation index = 1)
This function allows for the software’s interface language to be selected from amongst: English, French, German,
Spanish and Italian.
The set language is indicated with an arrow, for example: > Italian.
4.2 CALIBRATION MENU (menu navigation index = 2)
Please refer to the previous sections, in particular section 3.3 CALIBRATING THE OPERATING PARAMETERS.
1
--------------------
LANGUAGE
----------------------
ENGLISH
FRENCH
GERMAN
↓
↓↓
↓
1
---------------------
LANGUAGE
---------------------
GERMAN ↑
↑↑
↑
SPANISH
> ITALIAN
2
------------------
Calibration
----------------------
2A pH
2B ORP
2C CL
/Br
2
------------------
Calibration
----------------------
2B ORP ↑
↑↑
↑
2C CL/Br
2D Temperature
----------------------
SETUP
---------------------------
1 LANGUAGE IT
2 CALIBRATION
3 SETTINGS
↓
↓↓
↓
----------------------
SETUP
---------------------------
3 SETTINGS ↑
↑↑
↑
4 STATISTICS
5 ADVANC
ED
