4.4 STATISTICS MENU (4)
4.5 ADVANCED MENU (5)
Item Default Range Note
5A Password 0000 0000-9999
5B Control panel
5B1 Date/time 01/01/2000 - 00:00:00 00:00-23:59
5B2 Calibration key Enabled Enabled/Disabled
5B3 Mode key Enabled Enabled/Disabled
5B4 Output simulation Relay Sim.
Current output Sim.
Frequency Sim.
5B5 Input display Measurement inputs
Control inputs
5B6 Reset
5B7 Display Adjustment
5B8 Relay logic Change activation logic
5C Network (Serial Port)
RS485 Enabled Enabled/Disabled
Transmission speed 19200 2400-115000 Baud
Address 1 1-99
Parity Even No / Even / Odd
Stop bit 1 0,5 / 1 / 1,5 / 2
5D Text Free area for writing
messages
5E REED Management Flow alarm activation
delay time setting.
5E1 REED delay 2 sec. Time: 2-40 Sec.
5E2 REED logic NO Status: NC/NO
5F Dose Management Dosing system
activation delay time
setting.
5F1 START delay: OFF OFF Time: OFF/1-60 min
5F2 Calib. delay: OFF OFF Time: OFF/1-60 min
5G Cl/Br: Cl Cl/Br Select if the
amperometric measure
is Chlorine or Bromine
5G R4 Mapping (only graphic NTU) TORB TORB/TEMP Link R4 to NTU/Temp
Item
Default Value
Range
Statistics
Status:
Stop
Stop
-
Run
Mode:
Circ
Circular
–
List
Interval:
1
1
-
24
View Stat
istic:
System Stat.
Displays the status of the inputs
HOLD
REED
Level Probe 1
Level Probe 2
Measurement Stat.
Displays the status of the
chemical measurements
Stat.
Details
Displays the details of the
recorded measurements
Reset Stat.:
Resets all of
the parameters
4
------
------------
STATISTICS
---------------------
4A STATUS: STOP
4B MODE:
4C INTERVAL: 1
↓
↓↓
↓
4
------------------
STATISTICS
---------------------
4C INTERVAL: 1 ↑
↑↑
↑
4D VIEW STAT.
4E RESET STAT.
5
--------------------
ADVANCED
----------------------
5A PASSWORD
5B CONTROL PANEL
5C NETWORK
↓
↓↓
↓
5
--------------------
ADVANCED
----------------------
5D EDIT TEXT ↑
↑↑
↑
5E REED MANAGEMENT
5F DOSING DELAYS
