0000137242 Rev. 7.1 28
• Menu index “3B2” CHLORINE/BROMINE FREQU OUT
The frequency output (Open collector circuit) can be used to control and guide the dosing of a remote
system in proportion to the Chlorine measurement.
• Menu index “3B3” CHLORINE/BROMINE mA OUT
Note: The value set under the HOLD mA item is automatically generated by the instrument when a functional Hold
is present, for example due to a lack of water Flow Alarm or an enabled Voltage Input.
• Menu index “3B4” CHLORINE ALARM
Note: The Holding Range and Holding Time items must be used together.
The indicated function controls the chemical measurement at a constant value for long periods of time.
This alarm can help to prevent incorrect dosing as a result of damaged probes.
• Menu index “3B5” Reference temperature for CHLORINE/BROMINE measurement
Select 18, 20 or 25°C as the reference temperature for the chlorine measurement.
• Menu index “3B6” Compensation of chlorine/bromine based on conductivity of the water.
Select reference conductivity between Low less than 9 mS and High greater than 9 mS.
Item
Default Value
Range
FWM Standard:
SetPoint:
1.2 ppm
0
-
5
ppm
(0-12ppm for Br)
Dose
Type
:
Low
High / Low
Pulses/minute
:
20
pulses/minute
20
-
150
pulses
/minut
e
Proportional Band:
0.6 ppm
0.3
-
3 ppm
(0.1-7.2 ppm for Br)
Item
Default Value
Range
Standard Out mA:
Range 0/4
-
20mA:
4
-
20 mA
0
-
20 mA or 4
-
20 mA
Start (4): 0 pH
0 ppm
0
-
5
p
pm
(0-12ppm for Br)
End (20): 14 pH
10 ppm
0
-
5
ppm
(0-12ppm for Br)
Hold Function mA
Value: 0/4 or 20 mA
0 mA
0
-
20 mA
Item
Default Value
Range
pH Alarms List
Alarm minimum:
0.5 ppm
0
-
5
ppm
(0-12ppm for Br)
Alar
m Maximum:
1.8 ppm
0
-
5
ppm
(0-12ppm for Br)
OFA (Maximum dose timer):
Off
10
-
3600 Second
s
Holding range:
Off
0.2
-
3 ppm
(0.1-7.2 ppm for Br)
Holding time:
Off
1
0
-
3600 Seconds
Level Alarm: System stop or
alarm display
Disable
d
Enable
d
/Disable
d
3B2 CHLORINE
/BROMINE
FREQU OUT
SET POINT: 1.20ppm
DOSE TYPE LOW
PULSE: 20/min
↓
↓↓
↓
3B2 CHLORINE
/BROMINE
FREQU OUT
DOSE TYPE: LOW ↑
↑↑
↑
PULSE: 20/min
PROP BAND: 0.60ppm
3B3 CHLORINE
/BROMINE
mA OUT
RANGE: 4-20 mA
START( 4): 0.00ppm
END (20):
5.00ppm
↓
↓↓
↓
3A3 CHLORINE
/BROMINE
mA OUT
START( 4): 0.00ppm ↑
↑↑
↑
END (20): 5.00ppm
HOLD mA:
0.00mA
3B4 ALARMS
MIN VAL.: 0.50ppm
MAX VAL.: 1.80pppm
OFA:
OFF
↓
↓↓
↓
3B4 ALARMS
HOLDING RANGE: OFF ↑
↑↑
↑
HOLDING TIME: OFF
LEV ALARM: DISABLED
