Fluidwell E119-P Tutorial

E110-SERIES TUTORIAL AUTOMATIC UNIT CONVERSION
FW_E110_AutoUnitConv_002_EN Page 13
ACTION
RESULT
NOTICE
5. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
-
6. Press the ▲ button until
the TIME menu shows.
 The TIME menu shows.
-
7. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the time unit for
display purpose only.
8. Press the ▲ button to
make the required
selection.
 The selection /sec shows.
For the explanation,
the time unit for the flow rate is set
to /sec.
9. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
The flow rate is shown in the
selected period of time.
10. Press the ▲ button until
the DECIMALS menu
shows.
 The DECIMALS menu
shows.
-
11. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the decimal
pointer for display purposes only.
12. Press the ▲ button to
make the required
selection.
 The selection 0.1 shows.
For the explanation,
the decimals for the flow rate are
set to 1 decimal.
13. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
-
14. Press the ▲ button until
the K-FACTOR menu
shows.
 The K-FACTOR menu
shows.
Calculate the K-Factor for the
(accumulated) total by hand and
make a note.
15. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the calculated
K-Factor for the (accumulated)
total.
16. Use the ▲ button and
the ► button to enter
the required data.
 The K-FACTOR menu
shows 25.077.
For the explanation,
the K-Factor 6624.605 with an unit
m
3
converted into US GAL gives
6624.605 : 264.17 = 25.077.
17. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
18. Press the ▲ button until
the K-F DECS menu
shows.
 The K-Factor decimals
menu shows.
-
19. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the decimal
pointer.
20. Press the ▲ button to
make the required
selection.
 The selection 0 shows.
For the explanation,
the K-Factor decimals are set to
0 decimals.
21. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
-
