Fluidwell E119-P Tutorial

AUTOMATIC UNIT CONVERSION E110-SERIES TUTORIAL
Page 12 FW_E110_AutoUnitConv_002_EN
ACTION
RESULT
NOTICE
16. Press the ▲ button to
make the required
selection.
 The selection PLS 10
shows.
For the explanation,
the flow rate calculation is set to
PLS 10 for 10 pulses per
measurement unit.
17. Press the PROG button
momentarily.
 The PROG indicator
goes off.
 The selection is
confirmed.
-
18. Press the ▲ button until
the CUT-OFF menu
shows.
 The CUT-OFF menu
shows.
When during the cut-off time no
pulses are received, the E-series
will show a zero flow. This prevents
the E-series to continuously show
the last calculated flow rate while
there is no flow anymore.
19. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the cut-off time in
seconds.
20. Press the ▲ button and
the ► button to make
the required selection.
 The selection 15.0
shows.
For the explanation,
the cut-off time is set to
15 seconds.
21. Press the PROG button
momentarily.
 The PROG indicator
goes off.
 The selection is
confirmed.
-
22. Press the PROG button
until the operator menu
shows.
 The setup is completed.
-
2.3.2 The flow rate - HAND mode
This procedure gives the information how to setup the HAND mode. The HAND mode is
selected when the required measurement unit is not supported by the automatic unit
conversion.
NOTICE
This procedure is applicable for the HAND mode where the K-Factor for the flow
rate is set by hand. For the explanation, US GAL is the selected measurement
unit for the flow rate.
ACTION
RESULT
NOTICE
1. Press the PROG button
until the FLOWRATE
menu shows.
 The FLOWRATE menu
shows.
In this menu you can setup the
reading for the flow rate.
2. Press the ▲ button until
the UNIT menu shows.
 the UNIT menu shows.
-
3. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the measurement
unit for the flow rate.
A change of the measurement unit
requires also a new calculation of
the K-Factor for the flow rate. The
calculation is not done
automatically!
4. Press the ▲ button to
make the required
selection.
 The selection US GAL
shows.
For the explanation,
the measurement unit for the flow
rate is set to US GAL.
