Fluke Calibration 5560A - RS-232 Serial Connector

5560A/5550A/5540A
Remote Programmers Manual
14
Figure 2. IEEE-488 Connector Pinout (connection side)
RS-232 Serial Connector
The 9 pin serial connector on the rear of the Calibrator interfaces to a computer or controller. The pin
assignments of the rear-panel serial connector conforms to EIA/TIA-574 standard and is shown in
Figure 3.
Serial connection cables available from Fluke Calibration are listed in Table 6.
Table 6. Serial Port Connection Cables
Figure 3. From RS-232 Port Connector Pinout
Connection Cable Fluke Calibration Part Number
RS-232 PC COM port (DB-9) PM8914/001
NFRD
IFC
ATN
E0I
DIO3
DIO1
SHIELD SRQ NDAC DAV DIO4 DIO2
LOGIC
GND
GND
10
GND
8
GND
6
DIO8 DIO6
GND
11
GND
9
GND
7
REN
DIO7 DIO5
123456789101112
1324 14151617181920212223
15
69
TRANSMIT DATA (Tx)
RECEIVED DATA (Rx)
DTE READY (DTR)
REQUEST TO SEND (RTS)
CLEAR TO SEND (CTS)
GROUND
