Fluke 114 Calibration Information

114, 115, 116, and 117
Calibration Information
4
Table 2. Accuracy Specifications
Function Range Resolution
Accuracy
± ([% of Reading] + [Counts])
Model
DC millivolts 600.0 mV 0.1 mV 0.5 % + 2 114, 115, 117
DC Volts
6.000 V
60.00 V
600.0 V
0.001 V
0.01 V
0.1 V
0.5 % + 2 114, 115, 117
DC, 45 to 500 Hz 500 Hz to 1 kHz
Auto-V LoZ
[1]
True-
rms
600.0 V 0.1 V
2.0 % + 3 4.0 % + 3
114, 117
45 to 500 Hz 500 Hz to 1 kHz
AC millivolts
[1]
True-
rms
600.0 mV 0.1 mV
1.0 % + 3
2.0 % + 3
114, 115, 117
AC Volts
[1]
True-
rms
6.000 V
60.00 V
600.0 V
0.001 V
0.01 V
0.1 V
1.0 % + 3 2.0 % + 3 114, 115, 117
Continuity 600 Ω 1 Ω
Beeper on < 20 Ω, off > 250 Ω; detects
opens or shorts of
500 μs or longer.
114, 115, 117
Ohms
600.0 Ω
6.000 kΩ
60.00 kΩ
600.0 kΩ
6.000 MΩ
40.00 MΩ
0.1 Ω
0.001 kΩ
0.01 kΩ
0.1 kΩ
0.001 MΩ
0.01 MΩ
0.9 % + 2
0.9 % + 1
0.9 % + 1
0.9 % + 1
0.9 % + 1
5.0 % + 2
114, 115, 117
Diode test 2.000 V 0.001 V
0.9 % + 2
115, 117
Capacitance 1000 nF
10.00 μF
100.0 μF
9999 μF
1 nF
0.01 μF
0.1 μF
1 μF
1.9 % + 2
1.9 % + 2
1.9 % + 2
100 μF - 1000 μF: 1.9 % + 2
> 1000 μF: 5 % + 20
115, 117
Lo-Z Capacitance
(Power-up option)
1 nF to 500 μ
F
10 % + 2 typical
115, 117
Lo-Z Capacitance (Power-up option)
AC Amps True-
rms
[1]
(45 Hz to 500 Hz)
6.000 A
10.00 A
[3]
20 A for 30
seconds
max., 10
minutes
rest min.
0.001 A
0.01 A
1.5 % + 3 115, 117
DC Amps
6.000 A
10.00 A
[3]
20 A for 30
seconds
max., 10
minutes
rest min.
0.001 A
0.01 A
1.0 % + 3 115, 117

Fluke 114 Specifications

General

Frequency range	0.005 - 50 kHz
Continuity check	Yes
DC voltage range	0.0001 - 600 V
Resistance range	1 - 600 Ω
Resistance resolution	1 Ω
Resolution (DC voltage)	0.0001 mV
Basic accuracy (DC voltage)	1.0% + 3 (DC, 45 Hz to 500 Hz)
Temperature measurement range	-40 - 400 °C
Battery type	9V
Battery voltage	9 V
Number of batteries supported	1

Weight and Dimensions

Depth	46 mm
Width	84 mm
Height	167 mm
Weight	550 g
