Fluke 114 Calibration Information

Digital Multimeters
International Electrical Symbols
3
International Electrical Symbols
Table 1 lists the international symbols that appear in this document and on the Meter.
Table 1. Electrical Symbols
Symbol Description Symbol Description
B AC (Alternating Current) I Fuse
F DC (Direct Current) T Double Insulated
X Hazardous voltage W Important Information; Refer to manual
N Battery (Low battery when shown on the
display.)
J Earth ground
~ Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information.
General Specifications
Accuracy is specified for 1 year after calibration, at operating temperatures of 18 °C to 28 °C, with relative humidity at 0 % to 90 %.
Extended specifications are available at www.Fluke.com.
Maximum voltage between any
terminal and earth ground ................................... 600 V
Surge Protection................................................... 6 kV peak per IEC 61010-1 600 V CAT III,
Pollution Degree 2
W Fuse for A input (115 & 117 only): ................. 11 A, 1000 V FAST 17 kA Fuse (Fluke PN 803293)
Display ................................................................... Digital: 6,000 counts, updates 4/sec
Bar Graph: 33 segments, updates 32/sec
Temperature .......................................................... Operating: -10 °C to + 50 °C
Storage: -40 °C to + 60 °C
Temperature Coefficient ...................................... 0.1 x (specified accuracy)/°C (<18 °C or >28 °C)
Operating Altitude ................................................ 2,000 meters
Battery ................................................................... 9 Volt Alkaline, NEDA 1604A / IEC 6LR61
Battery Life ............................................................ Alkaline: 400 hours typical, without backlight
Safety Compliances.............................................. Complies with ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA-C22.2 No 61010-1-04, UL 6101B
(2003) and IEC/EN 61010-1 2
nd
Edition for measurement Category III, 600 V, Pollution Degree
2, EMC EN61326-1
Certifications ......................................................... UL, P, CSA, TÜV, ; (N10140), VDE
IP Rating (dust and water protection) .................... IP42

Fluke 114 Specifications

General

Frequency range	0.005 - 50 kHz
Continuity check	Yes
DC voltage range	0.0001 - 600 V
Resistance range	1 - 600 Ω
Resistance resolution	1 Ω
Resolution (DC voltage)	0.0001 mV
Basic accuracy (DC voltage)	1.0% + 3 (DC, 45 Hz to 500 Hz)
Temperature measurement range	-40 - 400 °C
Battery type	9V
Battery voltage	9 V
Number of batteries supported	1

Weight and Dimensions

Depth	46 mm
Width	84 mm
Height	167 mm
Weight	550 g
