Fluke 1630 Calibration Information

Earth Ground Clamp
Calibration Adjustment
9
Table 4. Calibration Adjustment Steps (cont.)
Step Action
Meter
Function
Source
Applied
Value
Adjust
Expected
Result/Instruction
13 Enter Cal Mode Harmonic displays
14 ~ A
1 A /
60 Hz
Press Honce when
reading is stable.
[1]
15 ~ A
3 A /
60 Hz
Press Honce when
reading is stable.
[1]
16 ~ A
Calibrator and 6-in.
wire loop
10 A /
60 Hz
Press Honce when
reading is stable.
[1]
17 ~ A
Calibrator and 3
turns copper
magnet wire, 6-in.
diameter
30 A /
60 Hz
Press Honce when
reading is stable.
[1]
Note
[1] Disregard reading accuracy during these calibration steps.
The calibration adjustment is now complete.

Fluke 1630 Specifications

General

Control type	Buttons
Housing color	Red, Black, Yellow
Maximum voltage	1000 V
Built-in display	Yes
Display technology	LCD
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Battery size	AA
Battery technology	Alkaline
Battery life (measurements)	15
Number of batteries supported	4

Weight and Dimensions

Depth	48 mm
Width	105 mm
Height	283 mm
Weight	880 g
