Fluke 1777 User Manual

3 Phase Power Quality Analyzer
Before You Start
5
2. Remove the two screws.
3. Remove the WiFi/BLE module with a gentle pull on the tether.
Figure 1. WiFi/BLE Module Installation
4. Close the protection cap.
To u p g r a d e :
1. Unscrew the two screws and dispose of the blind plate.
2. Insert the WiFi/BLE module into the correct slot.
3. Fasten the two screws.
4. Make sure the sealing area is clean and close the protection cap.
The WiFi/BLE module supports the connection to a WiFi infrastructure and direct connection
from a PC to the Analyzer. The module includes an internal antenna.
A router signal is sometimes weak due to factors such as obstacles, power, output, and
distance. The WiFi/BLE module supports an external 2.4 GHz/5 GHz WiFi antenna that can
boost the WiFi range of your signal for a more reliable WiFi signal.
31 2

Fluke 1777 Specifications

General

Category	Power Quality Analyzer
Safety Rating	CAT IV 600 V, CAT III 1000 V
Warranty	3 years
Voltage Measurement Range	1000 V AC/DC
Harmonics	Up to 50th harmonic
Display	LCD color display
Communication	USB
Operating Temperature	-10°C to +50°C
Battery Type	Lithium-ion battery pack
