77/75/23/21 English Instruction Sheet
Page
5
Diode Test
(G)
RANGE
CAT
+
__
Forward Bias
Single Beep
RANGE
CAT
CAT
+
Reverse Bias
_
RANGE
CAT
CAT
+
Shorted
Open
and
Good Diode Good Diode
Bad Diode
_
RANGE
CAT
CAT
+
Bad Diode
hc5f.eps
