Calibration Information
4
Table 1. Specifications (cont.)
Accuracy specifications are given as: ± ([% of reading] + number of least significant digits) ac readings
are ac-coupled, true rms, and are valid from 5 % to 100 % of range. Add ±(2 % of reading + 2 % of
range) for 1.4 < CF ≤ maximum CF. Maximum CF is 3 full scale, 6 half scale.
Function Range Resolution Accuracy Burden Voltage (Typical)
K 400.0 mV 0.1 mV ±(1.9 %+4)
(45 Hz to 1 kHz) 4.000 V 0.001 V ±(1.9 %+2)
40.00 V 0.01 V ±(1.5 %+2) Not Applicable
400.0 V 0.1 V ±(1.5 %+2)
1000 V 1 V ±(1.5 %+2)
L 4.000 V 0.001 V ±(0.3 %+1)
40.00 V 0.01 V ±(0.3 %+1) Not Applicable
400.0 V 0.1 V ±(0.3 %+1)
1000 V 1 V ±(0.3 %+1)
m
L* 40.00 mV 0.01 mV ±(0.3 %+5) Not Applicable
400.0 mV 0.1 mV ±(0.3 %+1)
e 400.0 Ω 0.1 Ω±(0.4 %+2)
4.000 kΩ 0.001 kΩ±(0.4 %+1)
40.00 kΩ 0.01 kΩ±(0.4 %+1) Not Applicable
400.0 kΩ 0.1 kΩ±(0.6 %+1)
4.000 MΩ 0.001 MΩ±(0.4 %+1)
40.00 MΩ 0.01 MΩ±(1 %+3)
Capacitance 99.99 nF 0.01 nF ±(1.9 %+2)**
999.9 nF 0.1 nF ±(1.9 %+2)**
9.999 µF 0.001 µF ±(1.9 %+2)** Not Applicable
99.99 µF 0.01 µF ±(1.9 %+2)**
999.9 µF0.1 µF ±(1.9 %+2)**
9999 µF1 µF ±10 % Typical
R 400 Ω 0.1Ω 5 % Typical*** Not Applicable
40Ω
40 Ω* 0.01 Ω 5 % Typical***
(Lo-Ohms)
400 Ω 0.1 Ω 5 % Typical*** Not Applicable
G
2.450 V 0.001 V ±2 % Typical Not Applicable
* In 40 Ω and 40 mV ranges, thermals may introduce additional errors. Maximum accuracy is obtained when
both probe tips are maintained at the same temperature.
** Accuracy applies when measuring film capacitors or better and the open lead reading is subtracted from the
measurement. This meter uses a dc-type measurement technique.
*** Accuracy applies after lead resistance compensation.
