Series III Multimeter
Specifications
3
Specifications
Specifications are in Table 1. Accuracy is specified for a period of one year after calibration, at 18 °C to
28 °C (64 °F to 82 °F) with relative humidity to 90 %. ac conversions are ac-coupled and true rms
responding.
Table 1. Specifications
Display: Digital: 4000 counts, updates 4/sec
Analog: 63 segments, updates 40/sec
Frequency: 9,999 counts
Capacitance: 9,999 counts
Response Time of
Digital Display:
V ac <1.5 s (for upscale only)
V dc <1 s
Ω <1 s to 40 kΩ, <2 s to 4 MΩ, <10 s to 40 MΩ
Operating Temperature: 0 °C to 55 °C
Storage temperature: -40 °C to 60 °C
Temperature Coefficient: 0.1 x (specified accuracy)/ °C (<18 °C or> 28 °C)
Relative Humidity: 90 % (0 °C to 30 °C)
75 % (30 °C to 40 °C)
45 % (40 °C to 50 °C)
35 % (50 °C to 55 °C)
Altitude: Operating: 2,000 meters
Storage: 12,000 meters
Battery type: 9 V, NEDA 1604A or IEC 6LR61
Battery Life: 500 hrs typical with alkaline
Continuity Beeper: 4096 Hz
Vibration: Per MIL-T-PRF-28800F, Class III
Sinusoidal, Non Operating
Drop: 1 meter drop per IEC 1010-1
Enclosure: Conforms to IP-40 per IEC-529
Size (HxWxL): 3.7 cm x 8.9 - 7.8 cm x 19 cm
(1.5 in x 3.5 - 3.1 in x 6.55 in )
Weight: 365 g (12.9 oz)
EMC: V ac and A ac only: RF field = 3 V/m. Total accuracy = specified accuracy +
2.0 % of range. EN 61326-1: 1997
Surge Protection: 6 kV peak per IEC 1010-1, 1990-09
Safety: 600 V CAT III and 1000 V CAT II per ANSI/ISA-S82.01-94, UL3111-1,
CSA/CAN C22.2 No 1010.1-92, EN 61010 part 1:1993
Certifications:
, ,
TUV pending
