Fluke 321 Fluke 322 Fluke 333 Fluke 334 Fluke 335 Fluke 336 Fluke 337
Range 0 - 400.0 A 0 - 40.00 A 0 - 400.0 A 0 - 600.0 A 0 - 600.0 A 0 - 600.0 A 0 - 999.9 A
40.0 - 400.0 A
Accuracy 1.8% ± 5 counts 1.8% ± 5 counts 2% ± 5 counts 2% ± 5 counts 2% ± 5 counts 2% ± 5 counts 2% ± 5 counts
(50 - 60 Hz) (50 - 60 Hz) (50 - 60 Hz) (50 - 60 Hz) (50 - 60 Hz) (10 - 100 Hz) (10 - 100 Hz)
3.0% ± 5 counts 3.0% ± 5 counts 6% ± 5 counts 6% ± 5 counts
(60 Hz - 400 Hz) (60 Hz - 400 Hz) (100 - 400 Hz) (100 - 400 Hz)
Crest Factor ————2.4 @ 500 A3 @ 500 A 3 @ 500 A
(50/60 Hz) 2.0 @ 600 A 2.5 @ 600 A 2.5 @ 600 A
add 2% for C.F.>2 add 2% for C.F.>2 1.42 @ 1000 A
add 2% for C.F.>2
AC Response Averaging Averaging Averaging Averaging True-rms True-rms True-rms
Inrush Integration Time 100 mS 100 mS 100 mS 100 mS
Range —————0 - 600.0 A 0 - 999.9 A
Accuracy —————2% + 3 counts 2% + 3 counts
Range 0 - 400.0 V 0 - 400.0 V 0 - 600.0 V 0 - 600.0 V 0 - 600.0 V 0 - 600.0 V 0 - 600.0 V
0 - 600 V 0 - 600 V
Accuracy 1.2% + 5 counts 1.2% + 5 counts 1% + 5 counts 1% + 5 counts 1% + 5 counts 1% + 5 counts 1% + 5 counts
(50 - 400 Hz) (50 - 400 Hz) (50/60 Hz) (50/60 Hz) (50/60 Hz) (20 - 100 Hz) (20 - 100 Hz)
6% + 5 counts 6% + 5 counts
(100 - 400 Hz) (100 - 400 Hz)
AC Response Averaging Averaging Averaging Averaging True-rms True-rms True-rms
Range 0 - 400.0 V 0 - 600.0 V 0 - 600.0 V 0 - 600.0 V 0 - 600.0 V 0 - 600.0 V
0 - 600 V
Accuracy 1% + 5 counts 1% + 5 counts 1% + 5 counts 1% + 5 counts 1% + 5 counts 1% + 5 counts
Range 0 - 400.0 0 - 400.0 0 - 600.0 0 - 600.0 0 - 600.0 0 - 600.0 0 - 600.0
601 - 6000 601 - 6000 601 - 6000 601 - 6000
Accuracy 1% ± 5 counts 1% ± 5 counts 1.5% ± 5 counts 1.5% ± 5 counts 1.5% ± 5 counts 1.5% ± 5 counts 1.5% ± 5 counts
Continuity 30 Ω≤30 Ω≤30 Ω≤30 Ω≤30 Ω≤30 Ω≤30
Range 5.0 - 400.0 Hz
Accuracy ——————0.5% ±5 counts
Trigger Level ——————10 - 100 Hz 5 A
5 - 10 Hz,
100 - 400 Hz 10 A
MIN/MAX No No No No No No Yes
Backlight No No No No Yes Yes Yes
Display Hold Yes Yes Yes Yes Yes Yes Yes
Height 7.5” 7.5” 9.375” 9.375” 9.375” 9.875” 9.875”
Size Width 2.5” 2.5” 3.125” 3.125” 3.125” 3.125” 3.125”
Depth 1.4” 1.4” 1.625” 1.625” 1.625” 1.625” 1.625”
Jaw Opening 1” 1” 1.2” 1.2” 1.2” 1.7” 1.7”
Weight 8 oz. 8 oz. 11 oz. 11 oz. 11 oz. 11 oz. 11 oz.
Need Technical Assistance?
Call 1-800-44-FLUKE toll free in the U.S. or
(800) 36-FLUKE in Canada or (425) 446-5500
in other countries.
Optimum Energy Products Ltd.
#333, 11979 40th Street S.E.
Calgary, AB, CANADA T2Z 4M3
For more information call:
Toll free in North America
1-877-766-5412
Main line:
(403) 256-3636
Fax line:
(403) 256-3431
or e-mail us at:
infor@optimumenergy.com
www.MyFlukeStore.com
Fluke. Keeping your world
up and running.
Models 333, 334, 335,
336 and 337
Operating temperature
-14 °F to 122 °F
(-10 °C to 50 °C)
Altitude
2,500 meters
Battery life
(2) AA alkaline approximately
150 hours continuous, auto-
matic low battery indicator
Safety rating
IEC 1010-2-031, 600 V CAT III
Temperature de-rating
Add 0.1 x specified accuracy for
each ºC above 28 ºC or below
18 ºC
Storage temperature
-40 ºF to 140 ºF
(-40 ºC to 60 ºC)
Warranty
Three years
Models 321 and 322
Operating temperature
-14 °F to 122 °F
(-10 °C to 50 °C)
Altitude
2,000 meters
Battery life
(2) AAA carbon zinc approxi-
mately 100 hours continuous,
automatic low battery indicator
Safety rating
IEC 1010-2-031, 600 V CAT III
Temperature de-rating
< 18 °C, > 28 °C add 0.1 x
specified accuracy / °C
Storage temperature
-22 °F to 140 °F (-30 °C to 60 °C)
Warranty
Two years
600V
CAT III
Designed and
Conforms to
IEC 1010-2-031
Specifications (@23 ºC + 5 ºC RH 0 - 90%)
