Page #6 background imageLoading...
Page #6 background image
4
Operation
Fluke 416D
GB
D
F
I
E
P
NL
DK
NO
S
FIN
GR
TR
CZ
SK
PL
HU
RU
RO
CN
KOR
abnormal use, and before, during and after important
measurements.
Make sure the Fluke 416D optic is kept clean and that
there is no mechanical damage to the bumpers.
CAUTION:
In using the instrument for distance measure-
ments or for positioning moving objects (e.g. cranes,
building equipment, platforms, etc.) unforeseen
events may cause erroneous measurements.
Precautions:
Only use this product as a measuring sensor, not as
a control device. Your system must be configured and
operated in such a way, that in case of an erroneous
measurement, malfunction of the device or power
failure due to installed safety measures (e.g. safety
limit switch), it is assured that no damage will occur.
Switching on/off
1x briefly: the instrument and the laser are
switched on.
The display shows the battery symbol until
the next button is pressed.
Pressing this button for longer switches the
instrument off.
The instrument switches off automatically after
three minutes of inactivity.
Setting the instrument
Press long until the desired unit is displayed.
Possible units:
CLEAR
1x briefly: the last action is cancelled.
Illumination
1x briefly: the display illumination is switched on
or off.
Reference Point
Default reference point is from the rear of the instru-
ment.
The instrument can be set for the following measure-
ments:
To measure from an edge (see drawing {D}), fold
out the stop bracket until it snaps in for the first
time. See drawing {E}.
To measure out of a corner (see drawing {D}),
fold out the stop bracket until it snaps in, push
Distance Area Volume
1. 0.000 m
0.000 m² 0.000 m³
2. 0'0''
1
/
16
0.00 ft² 0.0 ft³
3. 0 in
1
/
16
0.00 ft² 0.0 ft³
4. 0.00 ft
0.00 ft² 0.0 ft³
