values in secondary display lines 1 and 2.
Indirect Measurement
The instrument can measure distances with the
Pythagorean method. This procedure facilitates in
measuring distances that are difficult to access.
Note: Adhere to the prescribed sequence of meas-
urements:
• All target points must be vertical or horizontal on
the surface of the wall.
• The best results are achieved when the instru-
ment is rotated around a fixed point (e.g. the
stop bracket is fully extended and the instrument
is placed against a wall).
• To take the measurement, the minimum/
maximum function can be called up. The minimum
value is used for measurements that must be at
right-angles to the target; the maximum distance
is used for all other measurements.
Note: Make sure that the first measurement and the
distance to be measured are at right angles. Use the
minimum/maximum function.
Indirect measurement - determining a
distance using 2 auxilliary measurements
See drawing {G}
1x briefly: the symbol is displayed.
The distance to be measured flashes in the symbol.
1x briefly: takes a measurement of the distance.
The second distance to be measured flashes in the
symbol.
1x briefly: takes a measurement of the hori-
zontal distance.
The result of the function is displayed in the primary
display.
If the button is pressed for a long time while
measuring a distance, maximum or minimum contin-
uous measuring is activated.
Indirect measurement - determining a
distance using 3 auxilliary measurements
See drawing {H}
2x briefly: the symbol is displayed.
The distance to be measured flashes in the symbol.
1x briefly: takes a distance measurement.
The second distance to be measured flashes in the
symbol.
1x briefly: takes a horizontal measurement.
The third distance to be measured flashes in the
symbol.
1x briefly: takes a measurement of the distance.
The result of the function is displayed in the primary
display.
If the button is pressed for a long time while
measuring a distance, maximum or minimum contin-
uous measuring is activated.
