Fluke 5730A/03 Getting Started Manual

Multifunction Calibrator
Electrical Specifications
31
Overshoot .............................................................. <10 %
Common Mode Rejection
....................................... 140 dB, dc to 400 Hz
Frequency
Ranges (Hz) ........................................................ 10.000 - 119.99
0.1200 k - 1.1999 k
1.200 k - 11.999 k
12.00 k - 119.99 k
120.0 k - 1.1999 M
Absolute Specification ........................................ ±0.0025 %
Resolution ........................................................... 11.999 counts
Phase Lock (Selectable Rear Panel BNC Input)
Phase Specification (except 1100 V range) ........ >30 Hz: ±1 ° + 0.05 °/kHz), <30 Hz: ±3 °
Input Voltage ....................................................... 1 V to 10 V rms sine wave (do not exceed 1 V for mV ranges)
Frequency Range ............................................... 10 Hz to 1.1999 MHz
Lock Range ......................................................... ±2 % of frequency
Lock-In Time ....................................................... Larger of 10/frequency or 10 msec
Phase Reference (Selectable Rear Panel BNC Output)
Range ................................................................. ±180 °
Phase Absolute Specification ............................. (except 1100 V range) ±1 ° at quadrature points (0 °, ±90 °, ±180 °)
elsewhere ±2 °
Stability ............................................................... ±0.1 °
Resolution ........................................................... 1 °
Output Level ....................................................... 2.5 V rms ±0.2 V
Frequency Range ............................................... 50 Hz to 1 kHz, usable 10 Hz to 1.1999 MHz
Resistance Specifications
5730A Resistance Specifications
Nominal Value
(Ω)
Absolute Specification of Characterized Value
±5 °C from calibration temperature
[1]
Relative ±1 °C
24 Hours 90 Days 180 Days 1 Year 24 Hours 90 Days
±ppm
99 % Confidence Level
0
1
1.9
10
19
100
190
1 k
1.9 k
10 k
19 k
100 k
190 k
1 M
1.9 M
10 M
19 M
100 M
50 μΩ
85
85
23
23
10
10
7
7
6
6
7
8
13
15
33
43
100
50 μΩ
95
95
25
25
11
11
7.2
7.2
7
7
8
10
14
17
37
47
110
50 μΩ
100
100
26
26
11.5
11.5
7.5
7.5
7.5
7.5
9
11
14.5
19
40
50
115
50 μΩ
110
110
27
27
12
12
8
8
8
8
10
12
15
21
46
55
120
50 μΩ
32
25
5
4
2
2
2
2
2
2
2
2
2.5
3
10
20
50
50 μΩ
40
33
8
7
4
4
3
3
3
3
3
3
5
6
14
24
60
