Fluke 5730A Getting Started Manual

Multifunction Calibrator
Unpack and Inspect the Calibrator
11
Unpack and Inspect the Calibrator
The 5730A Calibrator ships in a container that prevents shipping damage. Inspect the
Calibrator carefully for damage, and immediately report any damage to the shipper.
Instructions for inspection and claims are included in the shipping container.
When the Calibrator is unpacked, check for all the standard equipment listed in Table 3
and check the shipping order for additional items ordered.
Table 3. Standard Equipment
Item Model or Part Number
Calibrator 5730A
Mains Power Cord
See Table 2-2 and Figure 2-1 in the Operators
Manual.
5730A Getting Started 4290571
5730A Manual CD (Containing the Operators
Manual)
4290580
Certificate of Calibration No part number
Placement and Rack Mounting
Put the 5730A Calibrator on top of a bench or mount in a standard-width, 24-inch
(61-cm) deep equipment rack. For bench-top use, the Calibrator has non-slipping,
non-marring feet. To mount the Calibrator in an equipment rack, use the Rack Mount
Kit (Model Y5737) or the Rack Ear Kit (Model Y5738). Instructions are included
with the kit.
Warnings
To prevent possible electrical shock, fire, or personal injury, do
not restrict access to the Calibrator mains power cord. The
mains power cord is the mains disconnecting device. If access
to the power cord is inhibited by rack mounting, a properly-
rated accessible mains disconnecting switch must be provided
within reach as part of the installation.

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
