Maintenance
Disassembly and Reassembly
3
3-3
Case, Top
Switch Assembly
Actuator, Switch
Main PCA
Shield, Bottom
Foot
LCD
Conn.
Elastomeric
Conn.
Elastomeric
LCD to PCA
Support, Switch Assembly
Battery
Shock Absorber
Case, Bottom
Screw, THD Form, PH.P.STL,
5-14 x .750
as07f.eps
Figure 3-1. Models 12B and 18 Disassembled Unit
