Fluke 7 Series User Manual

12B/18/7 Series
Service Manual
4-2
To ensure prompt delivery of the correct part, include the following information when
you place an order:
• Instrument model and serial number
• Part number and revision level of the pca containing the part.
• Reference designator
• Fluke stock number
• Description (as given under the DESCRIPTION heading)
• Quantity
Manual Status Information
The Manual Status Information in Table 4-1 defines the assembly revision levels that are
documented in the manual. Revision levels are printed on each pca.
Table 4-1. Manual Status Information
Ref. or Option No. Assembly Name Fluke Part No. Revision Level
A1 PCB ASSEMBLY (FLUKE 12) 879002 M
A1 PCB ASSEMBLY (FLUKE 10/18) 878991 M
A1 PCB ASSEMBLY (FLUKE 7-300) 614963 M
A1 PCB ASSEMBLY (FLUKE 7-600) 614966 M
Newer Instruments
Changes and improvements made to the instrument are identified by incrementing the
revision letter marked on the affected pca. These changes are documented on a manual
supplement sheet which, when applicable, is included with the manual.
Parts Lists, Drawings, and Schematics
This section contains the parts lists, drawings, and schematics for the meters.
Note
This instrument may contain a Nickel-Cadmium battery. Do not mix with
the solid waste stream. Spent batteries should be disposed of by a qualified
recycler or hazardous materials handler. Contact your authorized Fluke
service center for recycling information.
P
Warning
To avoid fire or explosion, replace the fusible resistor only with
Fluke PN 867361.
