Parts and Schematics
Parts Lists, Drawings, and Schematics
4
4-3
Table 4-2. Models 12B, 18, and 18/AL Final Assembly
Reference
Designator Description
Fluke Stock
Number
Total
Quantity
A1 MAIN PCA (MODEL 12B) 879002 1
A1 MAIN PCA (MODEL 18) 878991 1
BT1 BATTERY, 9V, 0-15MA 696534 1
H1-4 SCREW, PH, P, AM THD FORM, STL, 5-14, .750 832246 4
J3 CONN, ELASTOMERIC, LCD TO PWB, 2.050 L 867247 1
J4 CONN, ELASTOMERIC, SWITCH TO PWB, .500 L 867242 1
MP2 CASE TOP, (PAD XFER & WINDOW, MODEL 12B) 614948 1
MP2 CASE TOP, (PAD XFER & WINDOW, MODEL 18) 614955 1
MP2 CASE TOP, (PAD XFER & WINDOW, MODEL 18/AL) 615192 1
MP5 ACTUATOR, SWITCH 203445 1
MP6 SUPPORT, SWITCH ASSEMBLY 879031 1
MP8 CASE, BOTTOM, YELLOW (MODEL 12B) 614864 1
MP8 CASE, BOTTOM, GRAY (MODEL 18) 614872 1
MP9 SHIELD, BOTTOM 878277 1
MP10 SHOCK ABSORBER 878983 1
MP11 FOOT, NON-SKID 885884 1
MP12 TEST LEADS 855742 1
S2 SWITCH ASSEMBLY (MODEL 12B) 614799 1
S2 SWITCH ASSEMBLY (MODEL 18) 614807 1
U3 LCD, 3.5 DIGIT, MULTIPLEXED 855226 1
TM1 12B/18 INSTRUCTION SHEET 602000 1
