Parts and Schematics
Parts Lists, Drawings, and Schematics
4
4-5
Table 4-3. Models 7-300 and 7-600 Final Assembly
Reference
Designator Description
Fluke Stock
Number
Total
Quantity
A1 MAIN PCA (MODEL 7-600) 614966 1
A1 MAIN PCA (MODEL 7-300) 614963 1
BT1 BATTERY, 9V, 0-15MA 696534 1
H1-4 SCREW, PH, P, AM THD FORM, STL, 5-14, .750 832246 4
J3 CONN, ELASTOMERIC, LCD TO PWB, 2.050 L 867247 1
MP2 CASE TOP, (PAD XFER & WINDOW, MODEL 7-600) 614930 1
MP2 CASE TOP, (PAD XFER & WINDOW, MODEL 7-300) 614922 1
MP5 ACTUATOR, SWITCH 203452 1
MP6 SUPPORT, SWITCH ASSEMBLY 879031 1
MP8 CASE, BOTTOM, YELLOW 614864 1
MP9 SHIELD, BOTTOM 878277 1
MP10 SHOCK ABSORBER 878983 1
MP11 FOOT, NON-SKID 885884 1
MP12 TEST LEADS 855742 1
U3 LCD, 3.5 DIGIT, MULTIPLEXED 855226 1
TM1 INSTRUCTION SHEET, FLUKE 7 602018 1
