716 English Instruction Sheet
Page
5
Pushbutton Functions
Pushbutton Function
U
Press to select a different pressure unit. For higher
pressure module inputs, inappropriate (out-of-
range) units are not available.
Press
O
on while pressing
U
to source loop
voltage.
D
Turns pressure reading damping on and off. With
damping on, the display does not update as
quickly.
Z
Press to zero the pressure display. Vent pressure
to atmosphere before you press this pushbutton.
With an absolute Pressure Module, see special
instructions below.
m
Press and hold to read the minimum pressure and
current readings since the power was turned on or
c
was pressed.
c
Press to clear the MIN and MAX memories.
M
Press and hold to read the maximum pressure and
current readings the power was turned on or
c
was pressed.
h
Press
h
to freeze the display. The
g
symbol appears on the display. Press
h
again to resume normal operation.
