Digital Multimeter
Performance Tests
21
INDUCTIVE
PICKUP
SPARK PLUG SIDE
OSCILLOSCOPE
FUNCTION GENERATOR
CH1
CH2
10
RESISTOR
WIRE LOOP
(14 AWG)
OUTPUT
RED
aad08f.eps
Figure 5. Setup for Inductive Pickup Test
