Fluke 8808A Getting Started Manual

8808A
Getting Started Manual
4
Symbols
Table 2 lists safety and electrical symbols that appear on the Meter or in this manual.
Table 2. Safety and Electrical Symbols
Symbol Description Symbol Description
W
Risk of danger. Important
information. See manual.
P Standby power ON / OFF
X
Hazardous voltage. Voltage > 30 V
dc or ac peak might be present.
J Earth ground
B AC (Alternating Current) E Capacitance
F DC (Direct Current) G Diode
D
or
C
AC or DC (Alternating or Direct
Current)
I Fuse
R
Continuity test or continuity beeper
tone
Y
Digital signal
Y Potentially hazardous voltage U Maintenance or Service
T Double insulated < Recycle
h
Static awareness. Static discharge
can damage parts.
~
Do not dispose of this product as
unsorted municipal waste. Contact
Fluke or a qualified recycler for
disposal.
CAT II
Measurement Category II is for
measurements performed on
circuits directly connected to the
low voltage installation.
CAT I
Measurement Category I is for
measurements not directly
connected to mains.
Unpacking and Inspecting the Meter
Every care is taken in the choice of packing material to ensure that your Meter will reach
you in perfect condition. If the Meter has been subject to excessive handling in transit,
there may be visible external damage to the shipping carton. In the event of damage, keep
the shipping container and packing material for the carrier’s inspection.
Carefully unpack the Meter from its shipping container and inspect the contents for
damaged or missing items. If the Meter appears damaged or something is missing,
contact the carrier and Fluke immediately. Save the container and packing material in
case you have to return the Meter.
Storing and Shipping the Meter
To prepare the Meter for storage or shipping, use the original shipping container if
possible, as it provides shock isolation for normal handling operations. If the original
shipping container is not available, use a box that is 17.5 x 15.5 x 8.0 inches, with
cushioning material that fills the space between the Meter and the sides of the box.

Fluke 8808A Specifications

General

Product type	Digital multimeter
Product color	Grey, White
Frequency range	0.2 - 2 kHz
AC current range	0.2 - 10 A
AC voltage range	0.2 - 750 V
DC current range	0.0002 - 10 A
DC voltage range	0.2 - 1000 V
Resistance range	200 - 100000000 Ω
Placement supported	Bench multimeter
Resistance resolution	0.001 Ω
Resolution (frequency)	0.0001 Hz
Resolution (AC current)	100 µA
Resolution (DC current)	1 µA
Resolution (DC voltage)	1 mV
Basic accuracy (frequency)	0.01%
Basic accuracy (DC current)	0.02 + 0.005
Basic accuracy (DC voltage)	0.015 + 0.003
Basic accuracy (resistance)	0.02 + 0.003
Display digits	5.5 digits

Weight and Dimensions

Depth	297 mm
Width	217 mm
Height	88 mm
Weight	2100 g
